Kuriyama Standard Wall Food Grade Braided PVC Hose 3/4 x 200 ft

Kuriyama Standard Wall Food Grade Braided PVC Hose 3/4 x 200 ft

Kuriyama Standard Wall Food Grade Braided PVC Hose 3/4 x 200 ft



General Applications
  • • Air and water lines

  • • Air breathing lines

  • • Deionized water

  • • Food & beverage dispensing

  • • Liquid food products

  • • Packaging machines

  • • Pneumatic lines

  • • Potable water transfer

  • • Powdered food products



Construction
  • • Tube – Crystal clear phthalate free PVC

  • • Reinforcement – Reinforced with spiraled polyester yarn and longitudinal orange tracer yarns for identification

  • • Cover – Crystal clear phthalate free PVC

Compliance Information

 In compliance with applicable FDA (03) requirements, NSF (12) certified, meets USDA (16), 3A (01), UL (15), RoHS (14) and USP (17) Class VI criteria.

Service Temperature [Min]

 25 ºF-4 ºC

Service Temperature [Max]

 150 ºF65 ºC

Features and Advantages

Features and Advantages


NSF 51 Certified Hose
  • – Hose material certified by NSF for use as a drinking water system component. NSF 51 printed directly on hose for easy inspector field verification.
NSF 61 Certified Material
  • – Tube material certified by NSF for use as a drinking water system component.
Braided and Longitudinal Fabric Reinforcements
  • – High tensile strength, food grade polyester yarn braid provides higher working pressures. Yarns also run the length of the hose reducing elongation and improving coupling retention.
Transparent
  • – Allows for visual confirmation of material flow.
Glass-Smooth Interior
  • – Ensures smooth flow of material and reduces material buildup.

Nominal Specifications

Size Code

 12

ID

 3/4 in19.1 mm

OD

 1.031 in26.2 mm

Max. Working Pressure at 70ºF (20ºC)


 150 psi

Max. Working Pressure at 122ºF (50ºC)


 85 psi

Standard Length

 200 ft

Weight per Pkg.

 43 lb
